75/65/48W Multi USB PD QC 3.0 Phone Charger Dual Protocol Type C Charger Accessorie Fast Charging for iPhone 12 Mini Pro Max Adapter Charger
Product Information
1.4Ports---（1PD+1QC3.0+2USB)
Maximum output 48W, High power supply efficiency. The output uses the latest intelligent power distribution technology.
2.5Ports---（2PD+1QC3.0+2USB)
Maximum output 65W, High power supply efficiency. The output uses the latest intelligent power distribution technology.
3.6 Ports---（2PD+2QC3.0+2USB)
Maximum output 75W , High power supply efficiency. The output uses the latest intelligent power distribution technology.
Ports Output Logic
(a). When there is only 1 TypeC port output, the maximum output can reach the highest point under PD protocol. The maximum output is 18W under QC protocol.
(b). When port Type C is used simultaneously with A1 or A2 or A3, the maximum output is 20V/1.5A 30W under PD protocol, and the maximum output is 18W under QC protocol.
(c). When A1, A2, A3 are used at the same time over 4A, the maximum output is 12V/1.5A 18W under PD or QC protocol;
When A1 port output, A2, A3 does not output, the maximum output under QC is 18W;
When A1 is used with A2 or A3 at the same time, the maximum output is 5V/2.5A, and there is no fast charging protocol.
(d).It must be an E-Marker wire to reach a power of 65W and above.
Specifications:
Colour: Black
Product size: 9.6*7*3cm (without base)
Wire: AC 150cm
Material: PC fireproof material
Input: 100-220V 50/60H
Package Included:
1*PD fast charger
1*Base
1*Charging cable
1*Instruction
